ASADA
Using 25% higher tensile strength than standard 304, Standard-BS is our standard product which is adopted for wide use such as 100 micron fine line or thin deposit printing for MLCC.
It is also used for sieving and filtration industries.
| SPEC | MESH COUNT | WIRE DIA. （mm） | SIEVE SIZE （mm） | OPENING RATE | THICKNESS（μm） | |||
|---|---|---|---|---|---|---|---|---|
| NORMAL | Calender | |||||||
| SOFT | MIDDLE | HEAVY | ||||||
| BS-500/16 | 500 | 0.016 | 0.035 | 47% | 36 ± 2 | 25 ± 2 | 20 ± 1 | 16 ± 1 |
| BS-500/19 | 500 | 0.019 | 0.032 | 39% | 41 ± 2 | 30 ± 2 | 25 ± 1 | 19 ± 1 |
| BS-400/19 | 400 | 0.019 | 0.045 | 49% | 39 ± 2 | 34 ± 2 | 30 ± 1 | 23 ± 1 |
| BS-400/23 | 400 | 0.023 | 0.041 | 41% | 55 ± 2 | 40 ± 2 | 35 ± 1 | 25 ± 1 |
| BS-400/25 | 400 | 0.025 | 0.039 | 37% | 57 ± 2 | 49 ± 2 | 40 ± 1 | 30 ± 1 |
| BS-325/28 | 325 | 0.028 | 0.050 | 41% | 62 ± 2 | 55 ± 2 | 47 ± 1 | 40 ± 1 |
| BS-325/30 | 325 | 0.030 | 0.048 | 38% | 62 ± 2 | 60 ± 2 | 47 ± 2 | 42 ± 1 |
| BS-300/30 | 300 | 0.030 | 0.055 | 42% | 68 ± 2 | 59 ± 2 | 50 ± 2 | 45 ± 1 |
| BS-270/35 | 270 | 0.035 | 0.059 | 39% | 77 ± 2 | 70 ± 2 | 58 ± 2 | 40 ± 2 |
| BS-250/30 | 250 | 0.030 | 0.072 | 50% | 62 ± 2 | 58 ± 2 | 50 ± 2 | 45 ± 2 |
| BS-250/35 | 250 | 0.035 | 0.067 | 43% | 78 ± 2 | 64 ± 2 | 57 ± 2 | 55 ± 2 |
| BS-250/40 | 250 | 0.040 | 0.062 | 37% | 90 ± 3 | 86 ± 2 | 72 ± 2 | 67 ± 2 |
| BS-200/40 | 200 | 0.040 | 0.087 | 47% | 82 ± 3 | 77 ± 2 | 72 ± 2 | 63 ± 2 |
Hardmesh-Type MS
MS-Hardmesh is woven with 30% higher tensile strength wires than BS-Standard to meet Screen Printing demands such as high dimensional accuracy and screen mask longevity.
We were successful in developing 640 or 730 mesh, which are mainly used in MLCC industries. It is also appropriate for fine line printing and used for drawing 30 micron electrode lines in Touch Panel application.
| SPEC | MESH COUNT | WIRE DIA. （mm） | SIEVE SIZE （mm） | OPENING RATE | THICKNESS（μm） | |||
|---|---|---|---|---|---|---|---|---|
| NORMAL | Calender | |||||||
| SOFT | MIDDLE | HEAVY | ||||||
| MS-730/13 | 730 | 0.013 | 0.022 | 39% | 28 ± 2 | 20 ± 1 | 18 ± 1 | 15 ± 1 |
| MS-640/15 | 640 | 0.015 | 0.025 | 39% | 35 ± 2 | 25 ± 1 | 21 ± 1 | 17 ± 1 |
| MS-500/16 | 500 | 0.016 | 0.035 | 47% | 36 ± 2 | 25 ± 2 | 20 ± 1 | 15 ± 1 |
| MS-500/19 | 500 | 0.019 | 0.032 | 39% | 41 ± 2 | 36 ± 2 | 25 ± 1 | 20 ± 1 |
| MS-400/19 | 400 | 0.019 | 0.045 | 49% | 42 ± 2 | 30 ± 2 | 23 ± 1 | 18 ± 1 |
| MS-400/23 | 400 | 0.023 | 0.041 | 41% | 55 ± 2 | 40 ± 2 | 35 ± 1 | 26 ± 1 |
| MS-325/24 | 325 | 0.024 | 0.054 | 48% | 51 ± 2 | 44 ± 2 | 38 ± 2 | 25 ± 1 |
| MS-325/28 | 325 | 0.028 | 0.050 | 41% | 56 ± 2 | 51 ± 2 | 45 ± 2 | 39 ± 2 |
| MS-250/30 | 250 | 0.030 | 0.072 | 50% | 62 ± 2 | 58 ± 2 | 45 ± 2 | 28 ± 2 |
Supermesh-Type HS・SHS・UHS
By using stainless steel wires of 3 times higher strength than BS with low elongation, wires are woven at an open It’s “ratio” of 60%.
It is appropriate for solder bump or paste dropping printing.
| SPEC | MESH COUNT | WIRE DIA. （mm） | SIEVE SIZE （mm） | OPENING RATE | THICKNESS（μm） | |||
|---|---|---|---|---|---|---|---|---|
| NORMAL | Calender | |||||||
| SOFT | MIDDLE | HEAVY | ||||||
| HS-R-500/13 | 500 | 0.013 | 0.038 | 55% | 29 ± 3 | 24 ± 2 | 21 ± 1 | 17 ± 1 |
| SHS-430/13 | 430 | 0.013 | 0.046 | 61% | 29 ± 3 | 24 ± 2 | 21 ± 1 | 17 ± 1 |
| SHS-R-400/16 | 400 | 0.016 | 0.048 | 56% | 36 ± 3 | 25 ± 2 | 21 ± 1 | 15 ± 1 |
| SHS-380/14 | 380 | 0.014 | 0.053 | 62% | 32 ± 2 | 26 ± 2 | 20 ± 1 | 14 ± 1 |
| SHS-360/16 | 360 | 0.016 | 0.055 | 60% | 36 ± 3 | 32 ± 2 | 21 ± 1 | 16 ± 1 |
| SHS-325/16 | 325 | 0.016 | 0.062 | 63% | 35 ± 3 | 32 ± 2 | 20 ± 1 | 18 ± 1 |
| SHS-290/20 | 290 | 0.020 | 0.068 | 60% | 45 ± 3 | 36 ± 2 | 30 ± 1 | 20 ± 1 |
| HS-360/16 | 360 | 0.016 | 0.055 | 60% | 36 ± 3 | 32 ± 2 | 20 ± 1 | 16 ± 1 |
| HS-325/16 | 325 | 0.016 | 0.062 | 63% | 35 ± 2 | 32 ± 2 | 20 ± 1 | 17 ± 1 |
| HS-290/20 | 290 | 0.020 | 0.068 | 60% | 45 ± 2 | 36 ± 2 | 30 ± 1 | 20 ± 1 |
| HS-250/20 | 250 | 0.020 | 0.082 | 65% | 44 ± 2 | 37 ± 2 | 30 ± 1 | 18 ± 1 |
| HS-230/25 | 230 | 0.025 | 0.085 | 60% | 55 ± 2 | 40 ± 2 | 30 ± 2 | 27 ± 1 |
HS-D Mesh is a super strong mesh created using our unique Asada Mesh weaving technology. It is precisely woven with wire 3 times stronger than what has been used before, and has an opening rate of 40%, making it exceptionally strong under stress. Progress in improving mesh strength has been rapid.
Tensile strength of Supermesh HS-D is over 3 times greater than BS- Standard.
Produces more stable and dimensional accurate print plus it has an expected longevity of 2X-3X of conventional meshes.
Screen printing potential will be further enhanced.
Specification:
| SPEC | MESH COUNT | WIRE DIA. （mm） | SIEVE SIZE （mm） | OPENING RATE | THICKNESS（μm） | |||
|---|---|---|---|---|---|---|---|---|
| NORMAL | Calender | |||||||
| SOFT | MIDDLE | HEAVY | ||||||
| HS-D 650/14 | 650 | 0.014 | 0.025 | 41% | 34 ± 2 | 23 ± 2 | ||
| HS-D 500/19 | 500 | 0.019 | 0.032 | 39% | 45 ± 2 | 25 ± 1 | ||
| HS-D 360/25 | 360 | 0.025 | 0.046 | 42% | 59 ± 2 | 41 ± 2 | 29 ± 1 | |
| HS-D 250/35 | 250 | 0.035 | 0.067 | 43% | – | 44 ± 1 | ||
