HZI-TBZ-20IN
HANZE LTD
Screen Printing Pallet Tape For Platen Masking
HANZE LTD provide premium self-adhesive platen tape for use on print surfaces of textile screen print equipment. It is constructed with white translucent saturated paper and water-based natural rubber adhesive, which is designed specifically as the protector for textile printing pallets from ink spills, leaks, spray adhesives...Extends pallet life eliminates the need for cleaning solvents and reduces downtime for platen clean-up. If you're using a platen tape on your press, simply pull off the tape after a job and your pallet is clean. Premium platen tape also works on manual and other automatic platens. Adheres to either steel, aluminum or wood pallets.
Features:
A smooth paper tape with heat resistant adhesive
A self adhesive tape that easily applied
Easy removable ,no adhesive residue
Reduce pallet cleap-up time by 75%
Extend the life of your platen
Description:
1.Adhesion(g/25mm):400-700
2.Base Weight(g/㎡):70±3
3.Width(mm):410
4.Length(m):100
5.Storing(Months):12
6.Tensile strength(kg/cm):Horizontal≥3.0;Vertical≥4.0
7.Tear strength(mN):Horizontal≥600;Vertical≥500
Common Specification:
Width in Inch:12”,14”,16”,18”,20”,22”,24”,26”,28”,30”,32”...Max 48” or 52”
Width in centimeter:35 cm,40cm,45 cm,50 cm,55 cm,60 cm,65 cm,70 cm....Max 120 cm or 1320 mm
Roll Length:50 meters per roll,100 meters per roll,100 yards per roll
For other special specifications can provide cutting
Using process:
1.Make sure the platens are clean before applying the platen masking tape.
2.Apply the tape from the back with the sticky side down. Cut at the top of the platen.
3.Use the tape role or squeegee to slowly stick the tape to the platen ensuring there are no air bubbles. If you get an air bubble you can pull off and do again.
4.Use a sharp knife to poke a hole in any remaining air bubbles and press down to smooth out.
5.Mark on the tape before apply your adhesive spray.
6.Just remove the tape and it keeps your platen always clean.
Storage conditions:
Do not transport store with volatile organic solvent,avoid direct sunlight,rain.It should be stored at a temperature of 10℃ to 30℃ and a humidity of 40% to 70%.Buy for the best performance within 6 months after purchase.The platen mask should be placed.
Screen Printing Pallet Tape For Platen Masking
HANZE LTD provide premium self-adhesive platen tape for use on print surfaces of textile screen print equipment. It is constructed with white translucent saturated paper and water-based natural rubber adhesive, which is designed specifically as the protector for textile printing pallets from ink spills, leaks, spray adhesives...Extends pallet life eliminates the need for cleaning solvents and reduces downtime for platen clean-up. If you're using a platen tape on your press, simply pull off the tape after a job and your pallet is clean. Premium platen tape also works on manual and other automatic platens. Adheres to either steel, aluminum or wood pallets.
Features:
A smooth paper tape with heat resistant adhesive
A self adhesive tape that easily applied
Easy removable ,no adhesive residue
Reduce pallet cleap-up time by 75%
Extend the life of your platen
Description:
1.Adhesion(g/25mm):400-700
2.Base Weight(g/㎡):70±3
3.Width(mm):410
4.Length(m):100
5.Storing(Months):12
6.Tensile strength(kg/cm):Horizontal≥3.0;Vertical≥4.0
7.Tear strength(mN):Horizontal≥600;Vertical≥500
Common Specification:
Width in Inch:12”,14”,16”,18”,20”,22”,24”,26”,28”,30”,32”...Max 48” or 52”
Width in centimeter:35 cm,40cm,45 cm,50 cm,55 cm,60 cm,65 cm,70 cm....Max 120 cm or 1320 mm
Roll Length:50 meters per roll,100 meters per roll,100 yards per roll
For other special specifications can provide cutting
Using process:
1.Make sure the platens are clean before applying the platen masking tape.
2.Apply the tape from the back with the sticky side down. Cut at the top of the platen.
3.Use the tape role or squeegee to slowly stick the tape to the platen ensuring there are no air bubbles. If you get an air bubble you can pull off and do again.
4.Use a sharp knife to poke a hole in any remaining air bubbles and press down to smooth out.
5.Mark on the tape before apply your adhesive spray.
6.Just remove the tape and it keeps your platen always clean.
Storage conditions:
Do not transport store with volatile organic solvent,avoid direct sunlight,rain.It should be stored at a temperature of 10℃ to 30℃ and a humidity of 40% to 70%.Buy for the best performance within 6 months after purchase.The platen mask should be placed.
Substrate | parchment |
Adhesive | Natural Rubber-based |
Adhesion | 450-700(g/25mm) |
Color | White/translucent |
Thickness of Caliper Facestock | 105-115 microns |
Weight of Caliper Facestock | 70(g/㎡) |
Caliper Facestock+Adhesive | 135-148 microns |
Width | 1220mm/1320mm |
Length | 50mtrs/100mtrs/100 feet |
Tensile Strength(kg/cm) | Horizontal ≥3.0 |
Vertical ≥4.0 | |
Tear Strength(m/N) | Horizontal ≥650 |
Vertical ≥550 | |
Printing on Screen Printing Cotton | ≥19200 times |
Temperature of Dryer | 70℃-100℃ |
Shelf life | 1 year |
Substrate | parchment |
Adhesive | Natural Rubber-based |
Adhesion | 450-700(g/25mm) |
Color | White/translucent |
Thickness of Caliper Facestock | 105-115 microns |
Weight of Caliper Facestock | 70(g/㎡) |
Caliper Facestock+Adhesive | 135-148 microns |
Width | 1220mm/1320mm |
Length | 50mtrs/100mtrs/100 feet |
Tensile Strength(kg/cm) | Horizontal ≥3.0 |
Vertical ≥4.0 | |
Tear Strength(m/N) | Horizontal ≥650 |
Vertical ≥550 | |
Printing on Screen Printing Cotton | ≥19200 times |
Temperature of Dryer | 70℃-100℃ |
Shelf life | 1 year |
Application:
Pallet tape designed for use in textile screen printing to protect the platens from spray adhesive build-up.
Eliminates the need for costly solvents and rag disposal.
Apply to all kinds of printing machine (oval printing machine, octopus printing machine, etc.), as the cutting piece positioning.
Can also be used for hand-printed platen, embroidery platen positioning.
Application:
Pallet tape designed for use in textile screen printing to protect the platens from spray adhesive build-up.
Eliminates the need for costly solvents and rag disposal.
Apply to all kinds of printing machine (oval printing machine, octopus printing machine, etc.), as the cutting piece positioning.
Can also be used for hand-printed platen, embroidery platen positioning.
